Technical tips for Shell Eco-marathon teams

Here, you’ll find technical tips from the Shell Eco-marathon Technical Team, to help you prepare for your event and ace the Technical Inspection.

Before you begin to think about designing or building your vehicle, it’s worth getting your team organised and deciding roles and responsibilities within it. This event requires real dedication, so here are a few tips to ensure you’re prepared:

1. Define your team roles
   It’s important to decide who in your team is responsible for what, so define their roles. Appoint a Team Leader, a Safety Manager, a Logistics Coordinator and a confident Driver. It’s also a great idea to recruit mentors with prior experience.
2. Define your project
   Before you get started, your entire team should read the Rules. If you have any questions about these, please get in touch with us. Next, we advise drawing up an accurate budget and fundraising plan. Make sure your budget includes your shipping quotes, and contact your sponsors early on.
3. Before shipping
   Before you ship your vehicle, it should be fully built and test-driven. Try to get several hours of driving in a safe location prior to travelling to Shell Eco-marathon. Also, run your own Technical Inspection to be confident your vehicle is compliant before it arrives at the event. We’d urge you to take Technical Inspection very seriously. If your vehicle doesn’t comply with every rule, you won’t get access to the track. Aim to pass Technical Inspection on the first day.
4. Documents and communication
   Please print the required technical documents, as listed in Article 67 of the Rules, and bring them with you. Digital copies are not accepted. All Shell Eco-marathon Competition Rules and instructions are in English, so please ensure your team manager and driver(s) understand English.

While you’ll be thinking of ways to design super energy-efficient vehicle, it’s essential to build a vehicle that keeps your driver safe while they’re at the wheel. Here are some tips that should help.

1. A solid floor
   Every vehicle must have a solid floor that completely separates the driver’s compartment from the road.
2. The vehicle body
   The vehicle body needs to fully surround the driver, so no open-top compartments are permitted. The bodywork should have a solid and sturdy construction to protect the driver, so don’t use materials like thin film, cardboard or fabric. The bodywork also needs to cover all mechanical parts when viewed from above.
3. Make sure there’s a bulkhead
   The vehicle must have a bulkhead to separate your driver from the energy compartment in the event of a fire.

There also shouldn’t be any manual access from the driver to the energy compartment. The bulkhead should be made from a fire-retardant material like carbon fibre or sheet metal. If you’re using wood, you’ll need to add additional material to the energy compartment, such as aluminium.

Make sure the bulkhead reaches all the way to the top and sides of the vehicle, leaving no gaps between the body cover and the bulkhead. Try to run the wires underneath the bulkhead. If there are any gaps, try to fill them in with fire-retardant material like metal tape and protect the wires from chafing.

Additional tips for Urban Concept vehicles

If you’re building an Urban Concept vehicle, keep these extra tips in mind: Make sure the wheel covers are integrated into the bodywork. Your driver’s door opening needs a minimum dimension of 500 x 800mm and the chassis and bodywork must not infringe on this space, because the driver needs to be able to exit the vehicle in a quick manner.

Be prepared for your design check

Submit your technical drawings, photographs or animations of your entire vehicle in advance, so we can notify you if your design is non-compliant. For more information, make sure you read the Shell Eco-marathon Rules early, and get in touch if you have any questions.

Unfortunately, collisions do happen, and we want to make sure every driver is safe at Shell Eco-marathon. Here are the things you should know about roll bars and safety belts.

Roll bars

If your team’s vehicle rolls over, your driver will be relying on the roll bar for their protection. They must extend beyond the driver’s shoulder when seated in a normal driving position.

The roll bar must have a minimum of a five-centimetre gap around the entire racing helmet. It needs to be strong enough to endure at least a 70kg static load, and we’ll test this by applying this in several different directions during Tech Inspection.

As for its construction, it’s fine to use tubular steel or panel-type roll bars that are integrated into the chassis.

Safety belts

As for safety belts, we want to see either a five- or six-point belt system with the mounting points fitting to the strongest part of the vehicle and according to the manufacturer’s instructions.

The waist straps, which normally contain the locking system should be mounted 90 degrees to the floor for a Prototype vehicle, or between 45 and 60 degrees to the floor for an Urban Concept vehicle.

The belt should meet in the centre of the lower abdomen. Crotch straps should be mounted directly below the bottom of the driver’s spine. They may fasten directly into the locking mechanism, or loop through the waist straps and fasten via the shoulder straps.

Make sure the shoulder straps are mounted approximately 10 degrees below the shoulder. Once your driver’s safety belts are tightly fastened and you’ve got the excess straps secured, you should be good to go.

Remember, these safety measures should be in place before your driver begins practising. Even prior to Shell Eco-marathon. They should also wear their one-piece race suit, protective gloves and helmet. Please practise in a safe area, not on public roads. For more on this, take a look at Articles 26 and 29 in the Rules.

For Battery-Electric vehicles, we have banned store-bought motor controllers so that all teams learn about the requirements of their electric motor. Once the control requirements are understood, individual system components like a single-board control computer and the power driver stage can be specified and integrated into the system.

If you want to design your own controller or power stages and integrate them into a printed circuit board (PCB), that’s great, but please ensure that the letters “SEM” are etched onto the PCB to identify the board as custom-built for the Shell Eco-marathon event.

By the way, don’t be tempted to buy a controller and modify it, our eagle-eyed Technical Inspectors will spot it!

We want you to develop the motor controller yourself, so this also means we outlaw motor controller evaluation kits or the individual kit components, including software.

For more information about motor controllers, please see Article 66 of the Rules.
